MBR1535CT Dual Common Cathode Schottky Rectifier

MBR1535CT Description

www.vishay.com MBR(F,B)1535CT thru MBR(F,B)1560CT Vishay General Semiconductor Dual Common Cathode Schottky Rectifier TO-220AB ITO-220AB MBR15xxC.

MBR1535CT Features

* Guardring for overvoltage protection
* Low power loss, high efficiency
* Low forward voltage drop
* High forward surge capability
* High frequency operation
* Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C (for TO-263AB package)

MBR1535CT Applications

* For use in high frequency rectifier of switching mode power supplies, freewheeling diodes, DC/DC converters or polarity protection application. MECHANICAL DATA Case: TO-220AB, ITO-220AB, TO-263AB Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade Base

📥 Download Datasheet

Preview of MBR1535CT PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
MBR1535CT
Manufacturer
Vishay ↗
File Size
110.83 KB
Datasheet
MBR1535CT-Vishay.pdf
Description
Dual Common Cathode Schottky Rectifier
