V20120S Datasheet, Rectifier, Vishay

V20120S Features

• Rectifier
• Trench MOS Schottky technology
• Low forward voltage drop, low power losses
• High efficiency operation
• Solder bath temperature 275 °C max. 10 s, per

PDF File Details

Part number:

V20120S

Manufacturer:

Vishay ↗

File Size:

138.43kb

Download:

📄 Datasheet

Description:

High-voltage trench mos barrier schottky rectifier.

V20120S Application

• Applications For use in high frequency DC/DC converters, switching power supplies, freewheeling diodes, OR-ing diode, and reverse battery protection
