WED3DG64128V-D1 1GB - 128M X 64 SDRAM Unbuffered

The WED3DG64128V is a 128Mx64 synchronous DRAM module which consists of eight 128Mx8 stack SDRAM components in TSOP- 11 package, and one 2K EEPROM in an 8- pin TSSOP package for Serial Presence Detect which are mounted on a 144 Pin SO-DIMM multilayer FR4 Substrate. PIN CONFIGURATIONS (FRONT SIDE/BA.

WED3DG64128V-D1 Features

* n PC100 and PC133 compatible n Burst Mode Operation n Auto and Self Refresh capability n LVTTL compatible inputs and outputs n Serial Presence Detect with EEPROM n Fully synchronous: All signals are registered on the positive edge of the system clock n Programmable Burst Lengths: 1, 2, 4, 8 or Full
