XL5003 Datasheet, Driver, XLSEMI

XL5003 Features

• Driver n Operate from a rectified 85V~265V AC mains supply. n 0.2V current sense voltage reference. n Directly drive 2~8 series 1W LED. n Excellent line and load regulation. n Internal optimiz

PDF File Details

Part number:

XL5003

Manufacturer:

XLSEMI

File Size:

232.24kb

Download:

📄 Datasheet

Description:

600v 0.5a switching current buck pfm led constant current driver. The XL5003 is a monolithic high voltage switching regulator with PFM that is specifically designed to operate from a rectified 85V~26

XL5003 Application

• Applications n E27, GU10, GU5.3, B22 lamp device n LED daylight lamp n LED Lighting & LED LAMP n General purpose lighting Figure1. Package Type of
