MBRBU40100CT Schottky Diodes

MBRBU40100CT Description

MBRBU40100CT RoHS COMPLIANT Schottky Diodes .

MBRBU40100CT Features

* High frequency operation
* High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
* Guard ring for enhanced ruggedness and long term reliability

MBRBU40100CT Applications

* Typical applications are in switching power supplies, converters, freewheeling diodes, and reverse battery protection. Mechanical Data
* Package: TO-263 Molding compound meets UL 94 V-0 flammability rating, RoHS-compliant
* Terminals: Tin plated leads, solderable per J-STD- 002 and JESD22-B

📥 Download Datasheet

Preview of MBRBU40100CT PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
MBRBU40100CT
Manufacturer
Yangzhou Yangjie
File Size
241.43 KB
Datasheet
MBRBU40100CT-YangzhouYangjie.pdf
Description
Schottky Diodes
