AS5130 Datasheet - austriamicrosystems AG

AS5130 8 Bit Programmable Magnetic Rotary Encoder

The AS5130 is a contactless magnetic rotary encoder for accurate angular measurement over a full turn of 360º. It is a system-on-chip, combining integrated Hall elements, analog front end and digital signal processing in a single device. The angle can be measured using only a simple two-pole magnet .

AS5130 Features

* 360º contactless angular position encoding Two digital 8-bit absolute outputs: - Serial interface - Pulse width modulated (PWM) output User programmable zero position High speed: up to 30000 rpm Failure detection mode for magnet placement monitoring and loss of power supply Wide temperature range: -

AS5130 Datasheet (1.48 MB)

Preview of AS5130 PDF
AS5130 Datasheet Preview Page 2 AS5130 Datasheet Preview Page 3

Datasheet Details

Part number:

AS5130

Manufacturer:

austriamicrosystems AG

File Size:

1.48 MB

Description:

8 bit programmable magnetic rotary encoder.
