CY74FCT2573T 8-BIT LATCH

The CY74FCT2573T is an 8-bit, high-speed CMOS, TTL-compatible buffered latch with 3-state outputs that is ideal for driving high-capacitance loads, such as memory and address buffers. On-chip 25-Ω termination resistors at the outputs reduce system noise caused by reflections. The CY74FCT2573T can re.

D Function and Pinout Compatible With the Fastest Bipolar Logic D 25-Ω Output Series Resistors Reduce Transmission-Line Reflection Noise D Reduced VOH (Typically = 3.3 V) Version of Equivalent FCT Functions D Edge-Rate Control Circuitry for Significantly Improved Noise Characteristics D Ioff Supports Partial-Power-Down Mode Operation D Matched Rise and Fall Times D 3-State Outputs D ESD Protection Exceeds JESD 22 2000-V Human-Body Model (A114-A) 200-V Machine Model (A115-A) <.

CY74FCT2573T Datasheet (1.07 MB)
