INA200-Q1 Datasheet - Texas Instruments

INA200-Q1 Current-Sense Amplifier

The INA200-Q1, INA201-Q1, and INA202-Q1 (INA20x-Q1) are low- or high-side current-shunt monitors with voltage output. The INA20x-Q1 devices can sense drops across shunts at common-mode voltages from *16 V to +80 V. The INA20x-Q1 are available with three output voltage scales: 20 V/V, 50 V/V,.

INA200-Q1 Features

* 1 Qualified for Automotive Applications

* AEC-Q100 Qualified With the Following Results:

* Device Temperature Grade 1:

* 40°C to 125°C Ambient Operating Temperature Range

* Device HBM ESD Classification Level H2

* Device CDM ESD Classification Level C3
