ISO6761 Datasheet, Isolators, Texas Instruments

ISO6761 Features

• Isolators
• 50 Mbps data rate
• Robust isolation barrier:
    – High lifetime at 1500 VRMS working voltage
    – Up to 5000 VRMS isolation rating


PDF File Details

Part number:

ISO6761

Manufacturer:

Texas Instruments ↗

File Size:

2.95MB

Download:

📄 Datasheet

Description:

General-purpose six-channel reinforced digital isolators. The ISO676x devices are high-performance, sixchannel digital isolators ideal for cost-sensitive applications requiring up to 5000 VR

ISO6761 Application

• Applications
• Power supplies
• Grid, Electricity meter
• Motor drives
• Factory automation
• Building autom
