ISO7240CF Quad-Channel Digital Isolators

The ISO7240x, ISO7241x, and ISO7242x devices are quad-channel digital isolators with multiple channel configurations and output-enable functions. These devices have logic-input and logic-output buffers separated by Texas Instrument’s silicon-dioxide (SiO2) isolation barrier. Used in conjunction with.

ISO7240CF Features

* 25 and 150Mbps Signaling Rate Options

* Low Channel-to-Channel Output Skew; 1ns Maximum

* Low Pulse-Width Distortion (PWD); 2ns Maximum

* Low Jitter Content; 1ns Typ at 150Mbps

* Selectable Default Output ( ISO7240CF )

* > 25-Year Life at Rated Worki
