LM336-2.5-N

Reference Diode

LM336-2.5-N Features

* 1

* 2 Low Temperature Coefficient

* Wide Operating Current of 400 μA to 10 mA

* 0.2Ω Dynamic Impedance

* ±1% Initial Tolerance Available

* Specified Temperature Stability

* Easily Trimmed for Minimum Temperature Drift

* Fast Turn-On DESCRIPTION

LM336-2.5-N General Description

The LM136-2.5-N/LM236-2.5-N and LM336-2.5-N integrated circuits are precision 2.5V shunt regulator diodes. These monolithic IC voltage references operate as a low-temperature-coefficient 2.5V zener with 0.2Ω dynamic impedance. A third terminal on the LM136-2.5-N allows the reference voltage and temp.

LM336-2.5-N Datasheet (1.49 MB)

Preview of LM336-2.5-N PDF

Datasheet Details

Part number:

LM336-2.5-N

Manufacturer:

Texas Instruments ↗

File Size:

1.49 MB

Description:

Reference diode.
LM136-2.5-N www.ti.com SNVS749F

* MAY 1998

* REVISED APRIL 2013 LM136-2.5-N, LM236-2.5-N, LM336-2.5-NV Reference Diode Check for Sa.
