SN54LS173A - 4-BIT D-TYPE REGISTERS

The SN54LS173A by Texas Instruments is a 4-BIT D-TYPE REGISTERS. Below is the official datasheet preview.

📥 Download Datasheet

Official preview page of the SN54LS173A 4-BIT D-TYPE REGISTERS datasheet (Texas Instruments).

Datasheet Details

Part number SN54LS173A
Manufacturer Texas Instruments
File Size 482.36 KB
Description 4-BIT D-TYPE REGISTERS
Datasheet download datasheet SN54LS173A-etcTI.pdf
Additional preview pages of the SN54LS173A datasheet.

SN54LS173A Product details

Description

3Q 7 15 3D The ’173 and ’LS173A 4-bit registers include 4Q 8 14 4D 9 10 11 12 13 D-type flip-flops featuring totem-pole 3-state CLK GND NC G1 G2 outputs capable of driving highly capacitive or relatively low-impedance loads.The high-impedance third state and increased NC No internal connection high-logic-level drive provide these flip-flops with the capability of being connected directly to and driving the bus lines in a bus-organized system without need for interface or
