SN65LVDS94 - LVDS SERDES RECEIVER

Texas Instruments

SN65LVDS94 Datasheet Preview — Preview of SN65LVDS94 PDF

Datasheet Details

Part number	SN65LVDS94
Manufacturer	Texas Instruments ↗
File Size	614.96 KB
Description	LVDS SERDES RECEIVER
Datasheet	SN65LVDS94-etcTI.pdf

SN65LVDS94 Product details

Description

The SN65LVDS94 LVDS serdes (serializer/deserializer) receiver contains four serial-in 7-bit parallel-out shift registers, a 7× clock synthesizer, and five low-voltage differential signaling (LVDS) line receivers in a single integrated circuit.

Features

4:28 Data Channel Expansion at up to 1.904 Gigabits per Second Throughput.
Suited for Point-to-Point Subsystem Communication With Very Low EMI.
4 Data Channels and Clock Low-Voltage Differential Channels in and 28 Data and Clock Out Low-Voltage TTL Channels Out.
Operates From a Single 3.3-V Supply and 250 mW (Typ).
5-V Tolerant SHTDN Input.
Rising Clock Edge Triggered Outputs.
Bus Pins Tolerate 4-kV HBM ESD.
Packaged in Thi.
