74LVC1G98 Datasheet, Gate, nexperia

74LVC1G98 Features

• Gate
• Wide supply voltage range from 1.65 V to 5.5 V
• 5 V tolerant input/output for interfacing with 5 V logic
• High noise immunity
• ±24 mA output drive (

PDF File Details

Part number:

74LVC1G98

Manufacturer:

nexperia ↗

File Size:

268.86kb

Download:

📄 Datasheet

Description:

Low-power configurable multiple function gate. The 74LVC1G98 is a configurable multiple function gate with Schmitt-trigger inputs. The device can be configured as any of the follow

74LVC1G98 Application

• Applications using IOFF. The IOFF circuitry disables the output, preventing the damaging backflow current through the device when it is powered down
