NEX80605DA Datasheet, Controller, nexperia

NEX80605DA Features

• Controller
• Wide VCC range (10 V-83 V) supports PD/PPS
• Direct GaN driver
• Valley switching operation in QR/DCM/PFM
• Burst Mode with ultra-low operation current

PDF File Details

Part number:

NEX80605DA

Manufacturer:

nexperia ↗

File Size:

367.85kb

Download:

📄 Datasheet

Description:

Wide vcc range quasi-resonant flyback controller. The NEX806 device series (NEX806xx) are high frequency quasi-resonant PWM controllers implemented with peak current mode control. As

NEX80605DA Application

• Applications such as USB PD/PPS which require an output range between 3.3 V to 21 V . The NEX806xx offers comprehensive protection including output
