PDTA143EQA - NPN resistor-equipped transistor

Name: PDTA143EQA
SKU: PDTA143EQA-1338178

nexperia

📥 Download Datasheet

PDTA143EQA Datasheet Preview — Preview of PDTA143EQA PDF

Datasheet Details

Part number	PDTA143EQA
Manufacturer	nexperia
File Size	2.64 MB
Description	NPN resistor-equipped transistor
Datasheet	PDTA143EQA-nexperia.pdf

PDTA143EQA Product details

Description

100 mA PNP Resistor-Equipped Transistor (RET) family in a leadless ultra small DFN1010D-3 (SOT1215) Surface-Mounted Device (SMD) plastic package with visible and solderable side pads.

Features

100 mA output current capability.
built-in bias resistors.
simplifies circuit design.
reduces component count.
reduced pick and place costs.
low package height of 0.37 mm.
AEC-Q101 qualified.
suitable for Automatic Optical Inspection (AOI) of solder joint 1.3.
