HDSP-511Y Datasheet General-Purpose SevenSegment Display

Manufacturer: Broadcom

Overview: HDSP-511x, HDSP-513x, and HDSP-515A 14.22-mm (0.56-in.) General-Purpose SevenSegment Display Data.

Download the HDSP-511Y datasheet PDF. This datasheet also includes the HDSP-511E variant, as both parts are published together in a single manufacturer document.

📥 Download Datasheet

HDSP-511Y general-purpose sevensegment display by Broadcom - Datasheet Preview

Datasheet Details

Part number	HDSP-511Y
Manufacturer	Broadcom
File Size	557.41 KB
Description	General-Purpose SevenSegment Display
Download	HDSP-511Y Download (PDF)

General Description

This 14.22-mm (0.56-in.) LED seven-segment display uses industry-standard size package and pinout.

The device is available in either common anode or common cathode.

The choice of colors includes High Efficiency Red (HER), Green, AlGaAs Red, and Yellow.

Key Features

Industry standard size.
Industry standard pinout 14.22-mm (0.56-in. ) DIP lead on 2.54 mm.
Choice of colors High Efficiency Red (HER), Green, AlGaAs Red, and Yellow.
Excellent appearance Evenly lighted segments package gives optimum contrast ± 50° viewing angle.
Design flexibility Common anode or common cathode Single digit Right-hand decimal point.
Categorized for luminous intensity Green and yellow categorized for color Devices HER HDSP-511E HDSP-513E.
