DTQ3404 Datasheet | Din-Tek Semiconductor

FEATURES - DT-Trench Power MOSFET - 15J DQG8,67HVWHG APPLICATIONS - Notebook PC Core - VRM/POL .din-tek.jp DFN3X3-8L Pin Configuration Top View PIN1 N-Channel MOSFET ABSOLUTE MAXIMUM RATINGS (TC = 25 °C, unless otherwise noted) PARAMETER SYMBOL Drain-Source Voltage Gate-Source Voltage Continuous Drain Current (TJ = 175 °C)a Pulsed Drain Currentb Single Pulse Avalanche Current Single Avalanche Energy Maximum Power Dissipationc TC = 25 °C ID TC = 100 °C IDM IAS EAS TC = 25 °C PD TC = 100 °C Operating Junction and Storage Temperature Range TJ, Tstg LIMIT 40 ± 20 58 45 232 26 169 85 42.5 -55 to +175 UNIT V A m J W °C THERMAL RESISTANCE RATINGS PARAMETER SYMBOL LIMIT UNIT Junction-to-Ambient (PCB Mount)d Junction-to-Case (Drain) Rth...
