MMBTA06 Datasheet NPN Medium Power Transistor

Manufacturer: Diodes Incorporated

Overview: MMBTA05/MMBTA06 NPN MEDIUM POWER TRANSISTOR IN SOT23.

MMBTA06 datasheet preview

Datasheet Details

Part number	MMBTA06
Manufacturer	Diodes Incorporated
File Size	293.26 KB
Description	NPN Medium Power Transistor
Datasheet	MMBTA06_DiodesIncorporated.pdf

Key Features

Epitaxial Planar Die Construction.
Ideal for Low Power Amplification and Switching.
Complementary PNP Type: MMBTA55 and MMBTA56.
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2).
Halogen and Antimony Free. “Green” Device (Note 3).
An automotive-compliant part is available under a separate datasheet (MMBTA05Q/MMBTA06Q) Mechanical Data.
Package: SOT23.
Package Material: Molded Plastic, “Green” Molding Compound. UL Flam.
