PESD5V0V1BL Overview
plastic surface-mounted package; 2 leads plastic surface-mounted package; 2 leads leadless ultra small plastic package;.
PESD5V0V1BL Key Features
- Bidirectional ESD protection of one line
- Very low diode capacitance: Cd = 11 pF
- Max. peak pulse power: PPP = 45 W
- Low clamping voltage: VCL = 12.5 V
- Ultra low leakage current: IRM < 1 nA
- ESD protection up to 30 kV
- IEC 61000-4-2; level 4 (ESD)
- IEC 61000-4-5 (surge); IPP = 4.8 A
- AEC-Q101 qualified
