2SB1261 - PNP Epitaxial Planar Silicon Transistors

Key Features

  • z High hFE hFE=100 to 400. z Low VCE(sat0 VCE(sat)≤0.3V. Pb Lead-free Production specification 2SB1261.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
2SB1261 PNP Transistor LGE
2SB1261 Silicon PNP transistor BLUE ROCKET ELECTRONICS
2SB1261 PNP Transistor JCET
2SB1261 PNP Epitaxial Silicon Transistor JILIN SINO
2SB1261-K Silicon NPN Power Transistor Inchange Semiconductor

Other Datasheets by Galaxy Microelectronics

Part Number Description
2SB1260 Power Transistor
2SB1202 PNP Epitaxial Planar Silicon Transistors
2SB1218A PNP Silicon Transistor
2SB1240 Medium Power Transistor
2SB1243 Power Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
PNP Epitaxial Planar Silicon Transistors FEATURES z High hFE hFE=100 to 400. z Low VCE(sat0 VCE(sat)≤0.3V. Pb Lead-free Production specification 2SB1261 ORDERING INFORMATION Type No. Marking 2SB1261 1261 SOT-89 Package Code SOT-89 MAXIMUM RATING operating temperature range applies unless otherwise specified Symbol Parameter Value Units VCBO Collector-Base Volage -60 V VCEO VEBO IC ICP IB PC Collector-Emitter Voltage Emitter-Base Voltage Collector Current Collector Power Dissipation Base current Collector Power Dissipation Tj ,Tstg Junction and Storage temperature range *1: When mountef on a 40*40*0.7mm ceramic board. -60 -7 -3 -5 -0.5 0.5 2 *1 -55 to +150 V V A A A W ℃ E126 Rev.A www.gmicroelec.
