BL2306BD
BL2306BD is N-Channel Enhancement Mode MOSFET manufactured by Galaxy Microelectronics.
N-Channel Enhancement Mode MOSFET BL2306BD
Features
- High dense cell design for extremely low RDS(ON)
- Rugged and reliable
Mechanical Data
- Case: SOT-23
- Molding pound, UL Flammability Classification Rating 94V-0.
- Terminals: Matte Tin Plated Leads, Solderable Per MIL-STD-202, Method 208.
BL2306BD SOT-23
Ordering Information
Part Number BL2306BD
Package SOT-23
Shipping 3000 pcs / Tape & Reel
Marking Code S6
Maximum Ratings (@TA=25℃ unless otherwise specified)
Parameter
Symbol
Value
Drain-Source Voltage
VDSS
Gate -Source Voltage
VGSS
±20
Continuous Drain Current
TA = 25℃ TA = 70℃
ID (Note1,2)
3.16 2.7
Pulsed Drain Current ,PW ≤ 300 us, Duty Cycle ≤...
