Datasheet Summary
HL700
1.55A Li-ion Battery Switching Charger with Integrated OTG Boost
Features
- Full Automatic and Efficient Charge
Sequence
Management for Large Capacity Lithium
- Full Range Programmable Charge Parameter
Battery through I2C patible Interface
- Automatic Conditioning, CC/ CV Charge
- Input Current Limit Threshold
Control, Termination and Recharge
- Input Voltage DPM Threshold
- 550-1450mA Programmable Charge
- Charge Termination Current
Current
- Support 1550mA Charge Current Using
- Charge Termination Voltage
- Charge Termination Enable
56mΩ Sensing Resistor
- 3MHz Synchronous PWM,1µH Low Profile
- - Support 3.4MHz I2C HJS Mode
USB OTG...
