HL7006 Description
icicroro HL7005/6 is a pact, flexible, high-efficiency, USB pliant switch-mode charge management device MM for single cell Li-ion and Li-polymer battery used in a lolo wide range of portable applications. The charge HHaa parameters can be programmed through I2C HL7005/6 provides a plete automatic threephase battery charging control: trickle charge, constant-current charge (CC) and constant voltage charge (CV) until...
HL7006 Key Features
- Full automatic and efficient charge
- 3MHz Synchronous PWM Controller
- Full Range Programmable Charge Parameter
- Automatic conditioning, CC/ CV charge
- Input current limit threshold
- 550-1500mA programmable Charge
- Input voltage DPM threshold
- Charge & termination current
- 3MHz Synchronous PWM,1µH low profile
- Charge termination Voltage
