INC1001AC1-T150 Datasheet | Isahaya Electronics Corporation

DESCRIPTION INC1001AC1 is a silicon NPN epitaxial type transistor. It is designed with high collector current and small VCE(sat). OUTLINE DRAWING 0.65 1.5 0.65 UNIT：mm 2.8 1.90 0.95 0.95 FEATURE - Super mini package for easy mounting - High collector current(IC=500m A) - Low collector saturation voltage (VCE（sat）<0.3Vmax；IC=100m A、IB=10m A) ① ② ③ APPLICATION For switching, Small type motor drive 1.1 0.8 0～0.1 0.13 MAXIMUM RATING（Ta=25℃） SYMBOL PARAMETER VCBO Collector to Base voltage VEBO Emitter to Base voltage VCEO Collector to Emitter voltage Collector current Collector dissipation(Ta=25℃) Tj Junction temperature Tstg Storage temperature - Mounted on glass epoxy board(46mm×19mm×1mm) Terminal Connector ①：Base ②：Emitter ③：Collector JEITA：SC-59 JEDEC：Similar to TO-236 RATING 80...
