BSR19
Features
Low current (max. 300 m A) High voltage (max. 160 V).
+0.1 2.4 -0.1
SOT-23
2.9+0.1 -0.1
0.4+0.1 -0.1
0.95+0.1 -0.1 1.9+0.1 -0.1
Absolute Maximum Ratings Ta = 25
Parameter
Symbol
Rating
Unit
Collector-base voltage
VCBO
BSR19A
Collector-emitter voltage
VCEO
BSR19A
Emitter-base voltage
VEBO
Collector current
300 m A
Peak collector current
600 m A
Base current
100 m A
Peak base current
100 m A
Total power dissipation
-...
