KI30N03DFN Datasheet N-channel MOSFET

Manufacturer: Kexin Semiconductor

Overview: SMD Type ■.

Key Features

  • s.
  • VDS (V) = 30 V.
  • IDMAX = 28 A.
  • RDS(ON) (at VGS = 10 V) < 18 mΩ TraMnOsiSsFtoErsT N-Channel MOSFET KI30N03DFN DFN3.3x3.3-8 Top View Bottom View Pin 1 Top View 1 8 2 7 3 6 4 5.
  • Absolute Maximum Ratings (TA = 25℃ unless otherwise noted) Drain-Source Voltage Gate-Source Voltage Continuous Drain Current, VGS @ 10V (Note 1) Parameter TC=25℃ TC=100℃ TA=25℃ TA=70℃ Pulsed Drain Current (Note 2) Avalanche Current Single Pulse Avalanche Energy (Note 3) TC=25℃ Po.
