RFN10NS8DFH
RFN10NS8DFH is Super Fast Recovery Diode manufactured by ROHM.
Features
1) Cathode mon dual type 2) Low switching loss 3) Low VF
ROHM : TO263S (D2PAK) JEITA : SC-83
1 : Manufacture Date
- Taping Dimensions (Unit : mm)
- Construction Silicon epitaxial planar type
TO263S
- Structure
Cathode
Anode Anode
- Absolute Maximum Ratings (Tc= 25°C)
Parameter
Symbol
Conditions
Limits Unit
Repetitive peak reverse voltage
Duty≦0.5
Reverse voltage
Direct reverse voltage
Average rectified foward current
Io
60Hz half sin wave , Resistive load
1/2Io per diode
Tc=75°C
Forward current surge peak
IFSM
60Hz half sin wave, one cycle non-repetitive at Tj=25°C, per diode
Operating junction temperature
Tj
- 150
°C
Storage temperature
Tstg
- - 55 to 150...
