AZ9733
Overview
- AZ9733 Quick connect terminals
- AZ9734 PCB terminals available
- 40 Amp contact rating
- High momentary carry current (60A)
- High operating temperature (125°C)
- Epoxy sealed versions available
- Metal or plastic mounting bracket available
- Resistor or diode parallel to coil available
- ISO/TS 16949, ISO140001 CONTACTS Arrangement SPST (1 Form A) SPDT (1 Form C) Max. Ratings Continuous current:45A at 23°C (N.C.) 60A at 23°C (N.O.) Switched power: 560W (SPST) 560W (N.O.) 420W (N.C.) Contact Ratings Switching Volage: 75VDC 1 form A 40A at 13.5Vdc, Res. 20A at 27Vdc, Res. 150A make peak inrush, 30A break at 13.5Vdc, Lamp. 80/33A make/break at 13.5Vdc, Ind. 1 form C N.O. 40A at 13.5Vdc, Res. 20A at 27Vdc, Res. 150A make peak inrush, 30A break at 13.5Vdc, Lamp. 80/33A make/break at 13.5Vdc, Ind. 1 form C 30A at 13.5Vdc, Res. N.C. 10A at 27Vdc, Res. 40A/20A make/break at 13.5Vdc, Ind. Material Resistance Silver tin oxide < 100 milliohms initially (6V, 1A voltage drop method) COIL Power At Pickup Voltage (typical) Max. Continuous Dissipation Temperature Rise Temperature
- 57W 4.5W at 20°C (68°F) 52°C (94°F) at nominal coil voltage Max. 130°C (266°F)
