AZ973
Overview
- Quick connect terminals
- 40 Amp contact rating
- High momentary carry current (60A)
- High operating temperature (110°C) d
- SPST (1 Form A), SPDT (1 Form C)
- Epoxy sealed versions available
- Metal or plastic mounting bracket available
- Resistor or diode parallel to coil available e
- ISO/TS 16949, ISO14000 u CONTACTS Arrangement tin Ratings
- Material Resistance SPST (1 Form A) SPDT (1 Form C) Resistive load: Max. switched power: 560W (SPST) 560W (N.O.) 420W (N.C.) Max. switched current: 40A (SPST) 40A (N.O.) 30A (N.C.) Max. switched voltage: 75VDC Silver tin oxide < 100 milliohms initially (6V, 1A voltage drop method) o COIL Power At Pickup Voltage c (typical) Max. Continuous Dissipation Temperature Rise is Temperature
