ATA2516

IR Receiver ASIC

ATMEL Corporation

ATA2516 Features

* Supply Voltage: 4.5 V to 5.5 V Automatic Sensitivity Adaptation (AGC) Automatic Strong Signal Adaptation (ATC) Carrier Frequency is 56 kHz; Adjusted by Zener Diode Fusing ±4% TTL and CMOS Compatible Applications

* All Kinds of IR Remote Cont

ATA2516 General Description

The IC ATA2516 is a complete IR receiver for data communication systems. The device is developed and optimized for use in carrier frequency modulated transmission applications. Its function can be described using the block diagram in Figure 1 on page 2. The input stage meets two main functions. Firs.

ATA2516 Datasheet (177.90 KB)
