Part number: AT90USB162
Manufacturer: ATMEL
File Size: 2.08MB
Download: 📄 Datasheet
Description: 8-bit Microcontroller
* High Performance, Low Power AVR® 8-Bit Microcontroller
* Advanced RISC Architecture
– 125 Powerful Instructions
– Most Single Cl.
The AT90USB82/162 AVR is supported with a full suite of program and system development tools including: C compilers, ma.
2.2.1 VCC
Digital supply voltage.
2.2.2 GND
Ground.
2.2.3
Port B (PB7..PB0) Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port B output buffers have symmetrical drive characteristics wi.
