HSMN-C150 Datasheet - Agilent Technologies

(HSMx-C110/170/190/191/150) SMT Chip LED

HSMN-C150 Features

* High brightness

* Small size

* Industrial standard footprint

* Diffused optics

* Top emitting or right angle emitting

* Compatible with IR soldering

* Compatible for use with light piping

* Available in 8 mm tape on 7" diameter reel

HSMN-C150 General Description

These small chip-type LEDs utilize high efficient InGaN/SiC material to deliver competitively priced high performance blue and green. These 525 nm green and 470 nm blue are unique hues which provide color differentiation to a product. These ChipLEDs come in either top emitting packages (HSMx-C170, C.

HSMN-C150 Datasheet (265.02 KB)

Preview of HSMN-C150 PDF

Datasheet Details

Part number:

HSMN-C150

Manufacturer:

Agilent Technologies

File Size:

265.02 KB

Description:

(hsmx-c110/170/190/191/150) smt chip led.
