AD8390 Datasheet - Analog Devices

High Output Current Differential Amplifier

AD8390 Features

* Voltage feedback amplifier Ideal for ADSL and ADSL2+ central office (CO) and customer premises equipment (CPE) applications Enables high current differential applications Low power operation Single- or dual-power supply operation from 10 V (±5 V) up to 24 V (±12 V) 4 mA total quiescent supply curren

AD8390 General Description

The AD8390 is a high output current, low power consumption differential amplifier. It is particularly well suited for the central office (CO) driver interface in digital subscriber line systems such as ADSL and ADS.

AD8390 Datasheet (759.66 KB)

Preview of AD8390 PDF

Datasheet Details

Part number:

AD8390

Manufacturer:

Analog Devices ↗

File Size:

759.66 KB

Description:

High output current differential amplifier.
