AD8392

Dual-Channel ADSL/ADSL2+ Line Driver

AD8392 Features

* Four current feedback, high current amplifiers Ideal for use as ADSL/ADSL2+ dual-channel Central Office (CO) line drivers Low power operation Power supply operation from ±5 V (+10 V) up to ±12 V (+24 V) Less than 3 mA/Amp quiescent supply current for full power ADSL/ADSL2+ CO applications (20.4 dBm

AD8392 General Description

The AD8392 is comprised of four high output current, low power consumption, operational amplifiers. It is particularly well suited for the CO driver interface in digital subscriber line systems, such as ADSL and ADSL2+. The driver is capable of providing enough power to deliver 20.4 dBm to a line, w.

AD8392 Datasheet (734.71 KB)

Preview of AD8392 PDF

Datasheet Details

Part number:

AD8392

Manufacturer:

Analog Devices ↗

File Size:

734.71 KB

Description:

Dual-channel adsl/adsl2+ line driver.
