ADP5024 Datasheet, Regulators, Analog Devices

ADP5024 Features

• Regulators Main input voltage range: 2.3 V to 5.5 V Two 1200 mA buck regulators and one 300 mA LDO 24-lead, 4 mm × 4 mm LFCSP package Regulator accuracy: ±1.8% Factory programmable or external adj

PDF File Details

Part number:

ADP5024

Manufacturer:

Analog Devices ↗

File Size:

746.43kb

Download:

📄 Datasheet

Description:

Regulators. The ADP5024 combines two high performance buck regulators and one low dropout (LDO) regulator in a small, 24-lead, 4 mm × 4 mm LFCSP

ADP5024 Application

• Applications Power for processors, ASICS, FPGAs, and RF chipsets Portable instrumentation and medical devices Space constrained devices GENERAL DESC
