HMC591LP5E Datasheet, Mmic, Analog Devices

HMC591LP5E Features

• Mmic Saturated Output Power: +33 dBm @ 20% PAE Output IP3: +41 dBm Gain: 18 dB DC Supply: +7.V @ 1340 mA 50 Ohm Matched Input/Output QFN Leadless SMT Packages, 25 mm2 Functional Diagram Ge

PDF File Details

Part number:

HMC591LP5E

Manufacturer:

Analog Devices ↗

File Size:

402.60kb

Download:

📄 Datasheet

Description:

Gaas phemt mmic. The HMC591LP5 & HMC591LP5E are high dynamic range GaAs PHEMT MMIC 2 Watt Power Amplifiers which operate from 6 to 9.5 GHz. The amplif

HMC591LP5E Application

• Applications The HMC591LP5 / HMC591LP5E is ideal for use as a power amplifier for:
• Point-to-Point Radios
• Point-to-Multi-Point Ra
