BCT4222A Datasheet, Switch, BROADCHIP

✔ BCT4222A Features

VCC Operating Range: 1.65V to 4.2V
Rail-to-Rail Signal Range
ON-Resistance Matching: 0.05 Ω (TYP)
ON-Resistance Flatness: 0.08Ω (TYP)
High Off Isolation: 57dB a

✔ BCT4222A Application

Cell Phones PDAs Portable Instrumentation Differential Signal Data Routings USB 2.0 Signal Routing General

PDF File Details

Part number:

BCT4222A

Manufacturer:

BROADCHIP

File Size:

316.51kb

Download:

📄 Datasheet

Description:

High-speed dpdt analog switch. The BCT4222A is a high bandwidth, fast double-pole double-throw (DPDT) analog switch. Its wide bandwidth and low bit-to-bit skew allo

📥 Download PDF (316.51kb)
