Description
BL082 5-4000 MHz Wideband Low Nosie Amplifier Preliminary Datasheet Device .
Typical Performance1
BeRex’s BL082 is a high performance LNA, based
Parameter
Frequency
on GaAs material with E-pHEMT process and pack- Vd = 5.
Features
* This can be operated at Vd of 3.3V and 5V
* N. F = 0.88 dB @ 900MHz at Demo board
* 31.6 dBm Output IP3 at 5dBm/tone at 2350MHz
* 20.9 dB Gain at 900MHz
* 19.5 dBm P1dB at 2140 MHz
* Lead-free/Green/RoHS Compliant SOT363 SMT Package
Part Marking (X:Wafer number)
BL8XOUT GN
Applications
* Base station Infrastructure/RFID
* Commercial/Industrial/Military wireless system
Applications Circuit
RFin
DC Block
RF Choke BL082
Bypass
Vd
RFout
DC Block
* External matching circuit : refer to the page 4 to 16
Parameter Vd = 3.3V 900
Gain 20.7
S11 -27
S22 OIP33
-26 26.3
