DAC7614 DIGITAL-TO-ANALOG CONVERTER

The DAC7614 is a quad, serial input, 12-bit, voltage output digital-to-analog converter (DAC) with guaranteed 12-bit monotonic performance over the *40°C to +85°C temperature range. An asynchronous reset clears all registers to either mid-scale (800H) or zeroscale (000H), selectable via the .

DAC7614 Features

* q LOW POWER: 20mW q UNIPOLAR OR BIPOLAR OPERATION q SETTLING TIME: 10µs to 0.012% q 12-BIT LINEARITY AND MONOTONICITY:

* 40°C to +85°C q USER SELECTABLE RESET TO MIDSCALE OR ZERO-SCALE q SECOND-SOURCE for DAC8420 q SMALL 20-LEAD SSOP PACKAGE APPLICATIONS q ATE PIN ELECTRONICS q PROCESS CONTR
