NE85619-T1-A Datasheet, Transistor, CEL

NE85619-T1-A Features

• Transistor
• Low Voltage Use.
• High fT : 4.5 GHz TYP. (@ VCE = 3 V, IC = 7 mA, f = 1 GHz)
• Low Cre : 0.7 pF TYP. (@ VCE = 3 V, IE = 0, f = 1 MHz)
• Low NF : 1.2 d

PDF File Details

Part number:

NE85619-T1-A

Manufacturer:

CEL

File Size:

4.33MB

Download:

📄 Datasheet

Description:

Npn silicon epitaxial transistor. The NE85619 / 2SC5006 is an NPN epitaxial silicon transistor designed for use in low noise and small signal amplifiers fromVHF band t
