MX3401A

P-Channel Enhancement Mode Power MOSFET

ChipSourceTek

Download Datasheet (831.08 KB)

MX3401A Datasheet Preview — Preview of MX3401A Datasheet

Datasheet Details

Part number:

MX3401A

Manufacturer:

ChipSourceTek

File Size:

831.08 KB

Description:

P-channel enhancement mode power mosfet.
MX3401A P-Channel Enhancement Mode Power MOSFET Description The MX3401A uses advanced trench techn.
The MX3401A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operat.

✔ MX3401A Features

Schematic diagram
VDS =-30V，ID =-4.2A
@VGS=-10V RDS(ON)(Typ.)=45mΩ
@VGS=-4.5V RDS(ON)(Typ.)=52mΩ
@VGS=-2.5V RDS(ON)(Typ.)=70mΩ
High power and current handing

✔ MX3401A Application

s G D General Features Schematic diagram
VDS =-30V，ID =-4.2A
@VGS=-10V RDS(ON)(Typ.)=45mΩ
@VGS=-
