DTM4602 Datasheet, Mosfet, Din-Tek

DTM4602 Features

• Mosfet
• Halogen-free According to IEC 61249-2-21 Definition
• TrenchFET® Power MOSFET
• 100 % Rg and UIS Tested
• Compliant to RoHS Directive 2002/95/EC APPLIC

PDF File Details

Part number:

DTM4602

Manufacturer:

Din-Tek

File Size:

399.93kb

Download:

📄 Datasheet

Description:

N- and p-channel mosfet.

DTM4602 Application

• Applications
• Motor Drive S1 1 G1 2 S2 3 G2 4 SO-8 8 D1 7 D1 6 D2 5 D2 D1 G1 S1 S2 G2 D2 ABSOLUTE MAXIMUM RATINGS (TA = 25 °C, unless
