AL5802LPL Datasheet, Driver, Diodes

AL5802LPL Features

  • Driver
  • Reference Voltage VREXT = 0.65V
  • -40 to +125°C Operating Temperature Range
  • 0.8V to 30V Open-Collector Output
  • Negative Temperature Coefficient

PDF File Details

Part number:

AL5802LPL

Manufacturer:

DIODES ↗

File Size:

1.44MB

Download:

📄 Datasheet

Description:

Led driver. The AL5802LPL combines a high-gain NPN transistor with a prebiased NPN transistor to make a simple, small footprint LED driver. Pin

Datasheet Preview: AL5802LPL 📥 Download PDF (1.44MB)
