DFP840 Datasheet, Mosfet, DnI

DFP840 Features

• Mosfet RDS(on) (Max 0.85 )@VGS=10V Gate Charge (Typical 48nC) Improved dv/dt Capability High ruggedness 100% Avalanche Tested 2.Drain BVDSS = 500V 1.Gate RDS(ON) = 0.85 ohm ID = 8A 3.Source

PDF File Details

Part number:

DFP840

Manufacturer:

DnI

File Size:

642.82kb

Download:

📄 Datasheet

Description:

N-channel mosfet. This N-channel enhancement mode field-effect power transistor using DI semiconductor’s advanced planar stripe, DMOS technology intend
