HCPL2503 Datasheet, Optocouplers, Fairchild Semiconductor

✔ HCPL2503 Features

High speed
1 MBit/s
Superior CMR
10kV/µs
Dual-Channel HCPL2530/HCPL2531
Double working voltage
480V RMS
CTR guaranteed 0
70°C
U.L. recognized (File # E90

✔ HCPL2503 Application

Line receivers
Pulse transformer replacement
Output interface to CMOS-LSTTL-TTL
Wide bandwidth analo

PDF File Details

Fairchild Semiconductor manufacturer logo

Part number:

HCPL2503

Manufacturer:

Fairchild Semiconductor

File Size:

540.68kb

Download:

📄 Datasheet

Description:

High speed transistor optocouplers. The HCPL4502, HCPL2503, 6N135, 6N136, HCPL2530 and HCPL2531 optocouplers consist of an AlGaAs LED optically coupled to a high speed p

📥 Download PDF (540.68kb)
