TMC22051A - Multistandard Digital Video Decoder

Fairchild Semiconductor

📥 Download Datasheet

TMC22051A Datasheet Preview — Preview of TMC22051A PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: TMC22051A
Manufacturer: Fairchild Semiconductor
File Size: 413.98 KB
Datasheet: TMC22051A-FairchildSemiconductor.pdf
Description: Multistandard Digital Video Decoder

TMC22051A Product details

Description

The TMC22x5yA family of Digital Video Decoders offers unprecedented, broadcast-quality video processing performance in a single chip.

Features

Very high performance, low cost.
Adaptive comb-based decoding.
Multiple pin-compatible versions - 3-line, 2-line, and band-split - 8- and 10-bit processing.
Internal digital linestores.
Supports NTSC/PAL ﬁeld and NTSC frame based decoding.
Multiple input formats - CCIR-601/624 (D1), D2, CVBS, YC.
Multiple output formats - CCIR-601/624 (D1), RGB, YCBCR.
10-18 Mpps data rate.
Parallel and serial control interface.
