Part number:
GS9008
Manufacturer:
Gennum
File Size:
70.87 KB
Description:
Cable driver.
* two outputs, adjustable from 0 to 1100 mVp-p into 75 Ω loads
* nominal 600 ps rise and fall times
* accepts SMPTE and standard ECL input levels
* operates from a single +5 or -5 volt supply
* on-chip DC restoration for low jitter
* 170 mW power dissi
GS9008
Gennum
70.87 KB
Cable driver.
