LM1501BG - Step-Down Switching Regulator

Product Overview

HTC

LM1501BG Step-Down Switching Regulator by HTC - Datasheet Preview — Datasheet preview – LM1501BG

Datasheet Details

Part number	LM1501BG
Manufacturer	HTC
File Size	404.32 KB
Description	Step-Down Switching Regulator
Datasheet	LM1501BG Datasheet
Additional preview pages of the LM1501BG datasheet.

Product details

Description

The LM1501BG series of regulators are monolithic integrated circuits that provide all the active functions for a step-down switching regulator, capable of driving a 5A load with excellent line and load regulation.

Features

3.3V, 5V, 12V, and adjustable output versions.
Adjustable version output voltage range.
Guaranteed 5A output load current.
Input voltage range up to 40V.
300KHz fixed frequency internal oscillator.
Excellent line and load regulation.
Thermal shutdown and current limit protection TO-263-5L PKG TO-220-5L PKG.
