Description
www.DataSheet4U.com Agilent ACPM-7833 CDMA1900 (PCS) Power Amplifier Module Data Sheet .
The ACPM-7833 is a fully matched CDMA Power amplifier module.
Features
* Operating frequency: 1850
* 1910 MHz
* 28.5 dBm linear output power @ 3.4 V
* High efficiency: 40% PAE
* Dynamic bias control for low midpower Idd current with a single bias control voltage. For even lower quiescent current, a dynamic bias control circuit ca
Applications
* CDMA handsets
* Datacards
* PDAs
Vdd1
Vbias
Vdd2
Bias Circuit Power Input Match On Chip Inter-stage Match Passive Output Match
Input
Output
Vcntl
Single control bias setting for low Idq and 40% PAE at Pout = 28.5 dBm
